THE FLAME LIBERATOR

Just Delivered to Fayetteville, NC!

Including flame mirrors, hand grips, embroidered seat, and airbrushed realistic flame fenders. Front wheel is an RC Components 21" unit with the back wheels being 20" Giovannas. Drag handlebars wrap up the 2" over 40 mm Ultima front end. Let us know if we can build you a personalized Liberator Trike.

To see other images of the Flame Liberator check out the latest entry on our Gallery page.

  • Dimensions
    Overall Length
    120"
    Wheel Base
    88.6"
    Rear Tread Width
    63.5"
    Seat Height
    20.5"
    Rake
    37.5"
    Ground Clearance
    6"
    GVWR
    1,875 lbs.
    Dry Weight
    1,350 lbs.
  • Engine
    V-8
    Liquid Cooled
    H.P.
    275 @ 4800 rpm est.
    Torque
    355 @ 3200 rpm est.
    Block
    Cast Iron
    Heads
    Alluminum
    Pistons
    Hypereutectic
    Valves
    1.94" Int. / 1.5 Exh.
    Size
    Small Chevy
    Compression
    9.58:1
    Carburetor
    Edelbrock @ 500 cfm
    Exhaust
    2.5" w/ dual Supertrap Mufflers
  • Tires/Wheels
    Front
    130/90-16
    Rear
    235/50-18 (245/35-20 optional)
    Suspension
    Front
    41mm fluid dampened forks
    Travel
    3.5"
    Rear
    Single coil-over adjustable shocks
  • Brakes
    Front
    11" single disk, single piston
    Rear
    11" dual disk GM metric calipers
    Fuel
    Capacity
    13 gal
    Transmission
    Transaxle
    Modified 3 speed overdrive w/ lock-up converter
    Ratios
    2.84:1 final drive, 75:1 overdrive
